Model :
CBW-3200Type :
Diesel Engine PumpStroke :
200Cylinder Diameter :
170Flow :
885-3200 L/minPressure :
4.8-12 MpaShipping Port :
Shanghai Port, ChinaWarranty :
12 MonthsThe CBW-3200 diesel engine crude oil transfer pump is a horizontal triplex reciprocating single-acting plunger pump equipped with an automatic shift transmission and wireless remote control.
This equipment is suitable for conveying complex media such as high-viscosity crude oil, high-wax-content crude oil, and crude oil containing solid particles. Its robust and durable design ensures stable performance in harsh working environments. Additionally, the pump features high self-priming capability, enabling rapid pressure establishment during startup and reducing operational waiting time. The wireless remote control function enhances operational convenience, allowing personnel to operate from a safe distance, thereby reducing labor intensity and improving operational safety. The automatic transmission further optimizes operational efficiency by dynamically adjusting output power based on actual conditions, achieving energy savings and reduced consumption. This plunger crude oil transfer pump offers five flow and pressure specifications.
This crude oil transfer pump is equipped with a wireless remote control system, supporting touchscreen remote operation and enabling real-time monitoring via the display screen.
Features
1. With Cummins diesel engine；
2. Wireless remote control, improving efficiency；
3. Easy operation, reliable performance；
4. Good disassembly, easy maintenance and relocation.
Technical Parameters and Specifications
| Type | Horizontal Triplex Reciprocating Single Acting Plunger Pump |
| Stroke (mm) | 200 |
| Cyclinder Diameter (mm) | 170 |
| Flow (L/min) | 3200 2364 1752 1293 885 |
| Pressure (Mpa) | 4.8 6 8 10 12 |
| Input Speed (r/min) | 320 |
| Dimensions (mm) | 6120*2790*2450 |
| Weight (kg) | 13000 |
| Diesel Model | QSZ13-C550 |
| Diesel Engine Power (KW) | 410 |
| Rated Speed (r/min) | 1750 |
FAQ
1. Are crude oil transfer pumps suitable for conveying high-wax or high-viscosity crude oil?
They are highly suitable. Reciprocating pumps are among the preferred choices for transferring high-viscosity, high-pour-point crude oil. Prior to transfer, the crude oil typically requires heating to reduce viscosity, and reciprocating pumps can effectively overcome the flow resistance posed by high-viscosity liquids. The key is to ensure the heat tracing system is functioning effectively.
2. How to determine if pistons/plungers and seals need replacement?
Regularly inspect the piston/plunger surfaces for visible wear or scratches, while checking seals for leakage. If abnormalities are detected, replace them promptly to prevent reduced pump efficiency.
3. What are the common faults of automatic transmissions?
Common issues include abnormal shift logic, unusual noises, or vibrations. These problems may be caused by internal component wear or control system failures and require professional inspection and repair.
4. How do I test the signal strength of a wireless remote control system?
You can measure the signal coverage using the device's built-in signal detection feature or specialized instruments, ensuring no obstructions interfere with signal transmission.
5. What impact does excessively high lubricant temperature have on equipment?
Excessively high lubricant temperature may reduce lubrication effectiveness, increase component wear, and even cause equipment overheating and shutdown. Therefore, temperature rise issues must be promptly investigated and resolved.
The CBW-1200 diesel engine pump is primarily used for crude oil transfer and features five-speed flow adjustment functionality.
